Copy lathe machine for wooden handles - F14


Milling machine for handles production

Copying milling machine for handles turning and milling operations on straight and taper parts with max length 1400 mm. and having round, oval or irregular section; this unit works with two mechanic templates that enable to produce two different sections on the same item; on the machine are mounted cutterheads and special knives in accordance to shape that must be obtained on the workpiece.

Machine productivity can change from 2 to 6 pieces per minute according to workpieces length or shape. This units thanks to its high productivity rate is particularly suitable to produce agricultural tools handles, stairs spindles and posts ,painting or brush handles, tables and chairs legs as well as furniture fittings.



Description


Technical data:

Maximum size: 100 mm. Max. air consumption: 75 nl/minuto
Minimum length: 150 mm. Cutterhead rotation motor: 11 Kw.
Maximum length: 1400 mm. Feed motor for piece rotation: 0,37 Kw.
Productivity: 60/360 pcs./hour Feed motor for cam rotation: 0,37 Kw.
 Air pressure: 6 bar

Copy lathe machine F14 accessories:

Bottom Antivivration Device Copy Lathe Machine For Wooden Handles F14
Front Antivibration Device Copy Lathe Machine For Wooden Handles F14
Milling Equipment For Endshaping Copy Lathe Machine For Wooden Handles F14
Milling Unit Copy Lathe Machine For Wooden Handles F14


Video:


Mechanic wood lathe type F14 is suitable for production of:

Axle Wood Handle Copy Lathe Machine For Wooden Handles F14

Axle Wood Handle Copy Lathe Machine For Wooden Handles F14

Bellota Oval Handles Copy Lathe Machine For Wooden Handles F14

Bellota Oval Handles Copy Lathe Machine For Wooden Handles F14

Carpenter Wood Handle Copy Lathe Machine For Wooden Handles F14

Carpenter Wood Handle Copy Lathe Machine For Wooden Handles F14

Oval Hoe Handle Copy Lathe Machine For Wooden Handles F14

Oval Hoe Handle Copy Lathe Machine For Wooden Handles F14

Pick Wood Handle Copy Lathe Machine For Wooden Handles F14

Pick Wood Handle Copy Lathe Machine For Wooden Handles F14

Sledge Hammer Handle Copy Lathe Machine For Wooden Handles F14

Sledge Hammer Handle Copy Lathe Machine For Wooden Handles F14

Wood Hammer Handles Copy Lathe Machine For Wooden Handles F14

Wood Hammer Handles Copy Lathe Machine For Wooden Handles F14

Wood Handles Copy Lathe Machine For Wooden Handles F14

Wood Handles Copy Lathe Machine For Wooden Handles F14

Wood Hoe Handle Copy Lathe Machine For Wooden Handles F14

Wood Hoe Handle Copy Lathe Machine For Wooden Handles F14
